Reference Manual
00809-0100-4841, Rev. AA
May 2007
Rosemount 3490 Series
C-6
D753 Software Version - (Factory set) - - 5-7
HART D760 Manufacturer’s Code - (RMT) - - 5-7
D761 Unique ID - (Factory set) - - -
D762 Universal command revision - 5 - - -
D763 Txr spec. command revision - 1 - - -
D764 Pre-amble bytes - 5 - - -
D765 Flags - 1 - - -
MONITOR
(10)
READINGS ANSWERS D800 Primary Variable As P200 - - - 4-13, 5-4
D801 Secondary Variable As P201 - - - 4-13, 5-4
D802 Tertiary Variable As P202 - - - 4-13, 5-4
D803 Fourth Variable As P203 - - - 4-13, 5-4
D804 Ullage As P200 - - - 5-4
D805 % Current Output % - - - 5-4
D806 Current Output mA - - - 5-4
D809 Rate of change PV/min - - - 4-53, 4-59
RELAY RELAY
OPERATIONS
D811 Relay 1 Operations - 0 - - 4-56, 5-4
D812 Relay 2 Operations - 0 - - 4-56, 5-4
D813 Relay 3 Operations - 0 - - 4-56, 5-4
D814 Relay 4 Operations - 0 - - 4-56, 5-4
D815 Relay 5 Operations - 0 - - 4-56, 5-4
D820 Relay Status - - - - 5-4
RELAY
RUN TIME
D821 Relay 1 runtime hh:mm - - - 4-56, 5-4
D822 Relay 2 runtime hh:mm - - - 4-56, 5-4
D823 Relay 3 runtime hh:mm - - - 4-56, 5-4
D824 Relay 4 runtime hh:mm - - - 4-56, 5-4
D825 Relay 5 runtime hh:mm - - - 4-56, 5-4
D828 Totaliser 1 value
(5)
As P531 - 0 - 4-63, 5-5
D829 Totaliser 2 value
(5)
As P533 - 0 - 4-63, 5-5
D830 Alarm Report - None - - 4-60, 5-5
D831 Fault Report - None - - 4-52, 5-5
DIAGNOSTICS D835 Digital Input status - - - - 4-34, 5-6
D840 Current Input mA - - - 4-13, 5-6
D842 Current Input % % - - - 4-13, 5-6
D844 Temperature of Control Unit °C - - - 4-52, 5-6
D845 Time to next pump-down hh:mm - - - 4-54, 5-6
D846 Logging memory free
(7)
% - - - 4-35, 5-6
D848 Date of last change ddmmyy --/--/-- - - 5-6
D849 Data of 1st power-on ddmmyy --/--/-- - - 5-6
CHANNELS
(11)
D851 Channel 1 Output As P201 - - - 4-13, 5-7
D852 Channel 2 Output As P202 - - - 4-13, 5-7
MAIN MENU Menu Level 2 Menu Level 3 Menu Level 4
Param
Num.
Parameter Name Units
Factory
Defaults
Min Max
Reference
Pages
