Technical description
37 / 97
Display unit pilot lamps
Intake pressure monitoring system warning:
If the intake pressure drops below 1.5 bar (incl. tolerance) with intake pres-
sure monitoring system active the warning light is activated. The engine
speed is then automatically reduced until the intake pressure has risen
back to 1.5 bar.
Fuel reserve:
If the fuel level of the tank falls to below 15% a warning window will appear
to alert the operator to the need for refuelling. The warning window auto-
matically goes out when the fuel tank level goes over 15% (3 litres).
Ventilation warning:
If after 30 secs the automatic priming interrupts the priming process, since
no vacuum was achieved, the warning light is activated. When the priming
process restarts the warning goes out.
Service due warning:
If the operating hours until the next service are reached, the warning lights
are activated. However, if the date of the next service is reached no warning
is activated.
