L600N - Dual Band Wireless Router
6
LED Indicator
PRODUCT OVERVIEW
(From Left to Right)
• USB: Indicates when a USB device is connected to the USB port on
the right side of the Router. The LED blinks rapidly when data is
transmitted or received.
• Power: Indicates when the Router is powered on. The LED will
remain on.
• 2.4 GHz: Blinks rapidly when the wireless data traffic is transmitted
or received over the 2.4GHz wireless network.
• WPS: Wi-Fi Protected Setup activity. When the WPS mode is
activated the WPS LED blinks as it awaits a connection.
• Modem: Indicates when modem is connected to the modem port
on the back of the Router. The LED blinks rapidly when data is
transmitted or received.
• LAN: Indicates when a networking device is connected to a wired
port on the back of the Router. The LED blinks rapidly when wired
data traffic is transmitted or received.
• 5GHz: Blinks rapidly when wireless data traffic is transmitted or
received over the 5GHz wireless network.
