3.
Use the Dirctn knob to select the direction that the
wipe travels.
4.
Press the Dirctn knob to select whether the wipe
runs forward during the rst transition and then
reverse during the second (FF), or if it always goes
in the same direction.
5.
Press NEXT.
6.
Use the Pattrn knob to select the wipe pattern you
want to use. You can also select the pattern by
pressing the pattern button directly.
7.
Use the X Pos and Y Pos knobs to position the
wipe pattern. You can also use the positioner.
8.
Press NEXT.
9.
Use the Aspect knob to adjust the aspect ratio of
the wipe pattern.
Not all patterns can be adjusted.
10.
Use the Border and Soft knobs to apply a border
to the wipe pattern.
Refer to the section To Apply a Border to a Pattern
on page 24 for information on borders.
11.
Press NEXT. If a border is applied to the wipe, you
must press NEXT multiple times to get to the next
step.
12.
Use the Rot knob to rotate the pattern.
Not all patterns can be rotated.
13.
Use the HMult knob to multiply the pattern
horizontally.
14.
Use the VMult knob to multiply the pattern
vertically.
To Apply a Border to a Pattern
1.
Press WIPE > NEXT > NEXT.
2.
Use the Border knob to adjust the size of the border
around the pattern.
3.
Use the Soft knob to adjust the softness of the
pattern border.
4.
Press NEXT.
5.
Select a default or custom color for the border.
•
Default — use the Load knob to select a preset
color for the border.
•
Custom — press NEXT and use the BHue,
BSat, and BLum knobs to select your own
color.
DVE Transitions
A DVE transition is a gradual transition where one video
signal is replaced with another according to a 2D DVE
pattern.
Keep the following in mind when performing DVE
transitions:
• You must include the background when performing
a DVE transition on a Chroma Key, Self Key, or
Auto-Select Key. If you do not include the
background, a dissolve transition is performed.
• Performing a DVE transition on a DVE Key without
including the background scales the transition effect
to the size of the DVE Key. This transition does not
consume an additional DVE resource.
• Performing a DVE transition on a DVE Key with the
background included does not scale the transition
effect. This transition consumes the second DVE
resource.
To Set Up a DVE Transition
A DVE transition requires that you select the DVE
pattern and duration for the transition.
1.
Press DVE.
Tip: You can use the same procedure for a MiniME
™
or
MultiScreen.
2.
Use the Time knob to set the length of the
background transition.
Tip: Press ME RATE in the Effects Memory area for the
ME you want to change the rate for, use the keypad to enter
the new rate, and press Enter. (Does not apply to CB1 or
CB2.)
Tip: Press KEY RATE in the Effects Memory area
repeatedly to select the Keyer you want to set the rate for,
use the keypad to enter the new rate, and press Enter.
(Does not apply to CB1 or CB2.)
3.
Use the Dirctn knob to select the direction that the
wipe travels.
4.
Press the Dirctn knob to select whether the wipe
runs forward during the rst transition and then
reverse during the second (FF), or if it always goes
in the same direction.
5.
Press NEXT.
6.
Use the Effect knob to select the DVE pattern you
want to use. You can also select most of the patterns
by pressing the mnemonic pattern button directly.
•
PushL — Push Left
•
PushR — Push Right
•
PushU — Push Up
24 • Transitions — Graphite Operation Manual (v1.1)
