3.
Press DVE.
4.
Use the X Pos, Y Pos, and Size knobs to position
and size the key. You can also use the positioner.
5.
Press NEXT.
6.
Use the Aspect knob to adjust the aspect ratio of
the key.
7.
Use the Border knob to apply a border to the key.
Refer to the section To Apply a Border to a DVE
Key on page 35 for information on borders.
8.
Press NEXT.
9.
Crop the key horizontally as follows:
a)
Use the HCrop knob to crop the key
horizontally on both the left and right sides at
the same time.
b)
Press HCrop and use the Left/R knob to crop
the key horizontally on the left side only.
c)
Press Left/R and use the L/Rgt knob to crop
the key horizontally on the right side only.
10.
Crop the key vertically as follows:
a)
Use the VCrop knob to crop the key vertically
on both the top and bottom sides at the same
time.
b)
Press VCrop and use the Top/B knob to crop
the key vertically on the top side only.
c)
Press Top/B and use the T/Bttm knob to crop
the key vertically on the bottom side only.
11.
Press NEXT.
12.
Use the Freeze knob to freeze the key. You can
freeze the video and appearance of a key. When a
key is frozen, the DVE attribute menus are disabled
and you can not move the key or adjust DVE
attributes.
13.
Use the Mask knob to apply a mask to the key.
To Apply a DVE to a Key (Fly Key)
The DVE resources for this key may not be available.
Depending on how your switcher is congured, you may
be asked to steal the resources from another element, or
be prevented from using the resources.
You should set up your key as you want it before
applying the Fly Key.
1.
Press and hold SELF KEY, AUTO SELECT, or
CHR KEY for the key you want to apply the DVE
to and press DVE.
Tip: Hold the SELF KEY, AUTO SELECT, or CHR KEY
button again and press DVE to turn off the Fly Key.
2.
Press the KEY X SEL button for the key you are
setting up.
3.
Use the X Pos, Y Pos, and Size knobs to position
and size the key. You can also use the positioner.
4.
Press NEXT.
5.
Use the Aspect knob to adjust the aspect ratio of
the key.
6.
Use the Border knob to apply a border to the key.
Refer to the section To Apply a Border to a DVE
Key on page 35 for information on borders.
7.
Press NEXT. If a border is applied to the pattern,
you must press NEXT multiple times to get to the
next step.
8.
Crop the key horizontally as follows:
a)
Use the HCrop knob to crop the key
horizontally on both the left and right sides at
the same time.
b)
Press HCrop and use the Left/R knob to crop
the key horizontally on the left side only.
c)
Press Left/R and use the L/Rgt knob to crop
the key horizontally on the right side only.
9.
Crop the key vertically as follows:
a)
Use the VCrop knob to crop the key vertically
on both the top and bottom sides at the same
time.
b)
Press VCrop and use the Top/B knob to crop
the key vertically on the top side only.
c)
Press Top/B and use the T/Bttm knob to crop
the key vertically on the bottom side only.
10.
Use the Mask knob to apply a mask to the key.
To Apply a Border to a DVE Key
1.
Select the keyer that you want to set up a DVE key
border on.
Tip: You can use the same procedure for a MiniME
™
or
MultiScreen.
2.
Select the video signal, on the key bus, that you want
to use for the key.
3.
Press DVE.
4.
Use the Border knob to turn on the border and
adjust the size of the border around the key.
5.
Use the Soft knob to adjust the softness of the
border.
6.
Press NEXT.
7.
Select a default or custom color for the border.
Graphite Operation Manual (v1.1) — Keying • 35
