• You can stop a running custom control by pressing
the red custom control button on the custom control
bank.
• You can stop all running custom controls by selecting
a custom control with no events recorded to it.
• A maximum of 128 custom controls can be run at the
same time.
To Run a Custom Control
Once a custom control has been recorded, you can run
that custom control at any time.
1.
Press MENU.
2.
Select the bank that the custom control you want to
run is on by pressing the bank button.
3.
Select the custom control you want to run by
pressing the source button on the custom control
bus.
The custom control starts to play immediately.
Editing a Custom Control
After you have recorded a custom control, you can go
back and edit that custom control to add or remove
events.
Tip: Custom controls can also be edited from the Custom
Control node in DashBoard.
To Edit a Custom Control
When editing a custom control, you can delete and insert
events at any point in the custom control, or append
events to the end.
Tip: When editing a custom control, press RUN EVENT to run
the currently selected event. This can help you diagnose
problems in a custom control.
1.
Press MENU > BANK 1 > EDIT.
2.
Use the Bank knob to select the bank that the
custom control you want to record will be stored on,
or select the bank button directly.
3.
Use the CC knob to select the custom control that
you want to edit, or select the custom control on the
bus directly. The custom control will have an * next
to the number.
4.
Use the Func knob to select where and how you
want to edit the custom control.
•
Edit — select the position in the custom control
to edit events
•
Append — add events to the end of the custom
control
5.
Press the Func knob to start editing.
Tip: You can also start editing a custom control by pressing
and holding EDIT and selecting the bank and custom that
you want to edit to.
The display changes to show the name and duration
of the custom control, and the currently selected
event in the custom control.
6.
Delete an event in a custom control as follows:
a)
Use the left knob to select the event you want
to delete. You can also use the PREV and
NEXT buttons.
b)
Press DELETE.
7.
Insert an event into a custom control as follows:
a)
Use the left knob to select the event you want
to insert an event before. You can also use the
PREV and NEXT buttons.
b)
Press INSERT.
c)
Insert the events you want.
d)
Press START/STOP to nish recording.
Naming Custom Controls
Each custom control can be given a unique name and
mnemonic color. The name is shown in the mnemonic
display when CCMnem is set to Split or Full.
To Name a Custom Control
The procedure to name or rename a custom control is the
same.
1.
Press MENU > BANK 1 > EDIT
2.
Use the Bank knob to select the bank that the
custom control you want to name is stored on, or
select the bank button directly.
3.
Use the CC knob to select the custom control that
you want to name, or select the custom control on
the bus directly.
4.
Use the Func knob to select Rename.
5.
Press the Func knob.
6.
Select a name as follows:
a)
Use the Pos knob to select the character
position to edit. A name can have up to 8
character.
b)
Use the Char knob to select a character for the
current position.
7.
Press NEXT.
8.
Use the Size knob to select the text size for the
mnemonic label.
•
Small — 6 characters displayed on the top line,
and 2 on the bottom
