Audio Mixer
The audio mixer tab in DashBoard provides a graphical
interface to all the audio sources and mixer layers. An
audio channel must be routed to the switcher subsystem
to be controllable by the audio mixer interface. Audio
sources can come from the embedded audio on an input
BNC, through the 1RU Audio Breakout Module, from
the Media-Store, or from the Windows
®
sound mixer.
Note: The audio mixer interface is only available in DashBoard.
Audio Mixer Setup
The audio mixer has 4 mixer layers that can be congured
for which inputs are available to them and which physical
outputs they are routed to.
Note: The PC Audio input and output are routed through the
Windows
®
sound mixer.
To Set Up the Audio Mixer
The audio mixer works in conjunction with the 1RU
Audio Breakout Module to provide AES and analog XLR
inputs and outputs. Audio inputs and outputs are set up
both on the switcher subsystem and on the 1RU Audio
Breakout Module.
1.
Click Navigation Menu > Audio Mixer >
Config.
2.
For each audio output (Main, Aux 1, Aux 2, and
Aux 3) select the audio sources that you want to be
available on that layer.
•
SDI — stereo audio embedded on input BNC
1-12.
•
XP — stereo audio channels 1-4 from XPression.
•
Media1 — stereo audio from Media-Store 1
•
Media2 — stereo audio from Media-Store 2
•
PC — stereo audio from the Windows
®
operating system of the server.
•
AES — stereo AES audio from the AES input
on the 1RU Audio Breakout Module.
•
Analog1-8 — mono analog audio from the
Analog inputs on the 1RU Audio Breakout
Module.
Tip: You can change the order of the audio strips on the
mixer by moving a source Up (left) or Down (right) in the
list.
3.
Click an Analog X button and select the audio
channel that you want to send to that output on the
1RU Audio Breakout Module.
•
Main Left — the left stereo channel of the main
audio output.
•
Main Mono — the mono channel of the main
audio output.
•
Main Right — the right stereo channel of the
main audio output.
•
Monitor Left — the left stereo channel of the
monitor audio output.
•
Monitor Mono — the mono channel of the
main audio output.
•
Monitor Right — the right stereo channel of
the main audio output.
•
Aux X Left — the left stereo channel of aux 1-3
audio output.
•
Aux X Mono — the mono channel of aux 1-3
audio outputs.
•
Aux X Right — the right stereo channel of aux
1-3 audio outputs.
4.
Click the AES button and select the stereo output
that you want to send to the AES output on the 1RU
Audio Breakout Module.
•
Main — the stereo channels of the main audio
output.
•
Monitor — the stereo channels of the monitor
audio output.
•
Aux X — the stereo channels of the aux 1-3
audio outputs.
5.
Click the PC Audio button and select the stereo
output that you want to send to the Windows
®
audio
console.
•
Main — the stereo channels of the main audio
output.
•
Monitor — the stereo channels of the monitor
audio output.
•
Aux X — the stereo channels of the aux 1-3
audio outputs.
Audio Mixer Interface
The audio mixer interface allows you to control the mix
levels for all the incoming channels to a mix layer, as
well as the master level for the output of that layer. The
Main layer also has a monitor output and level.
Graphite Operation Manual (v1.1) — Audio Mixer • 43
