The ideal air speed for the unit CN+ 600 and CN+ 600 DC is about 1 m/sec (intake) and
corresponds to air flow rate of 600 m³/h; if lower or higher air speed is measured by over than
10%, the fan's power meter must be regulated in order to near the suitable speed as much as
possible; the power meter is default regulated at standard speed.
6.5.3 Serial RS485
Serial connection:$
A --> 1$
B --> 2$
To connect serial modbus RS485 with the unit refer to RS485 manual
6.6 Finishing
6.6.1 Assembly closing panel for unit IN+ 300 (optional)
NOTE:
After having tightened the 4 pins on the wood panel, this can be fixed on the casing, by completely
hiding the unit and casing.
Pull the panel from the 2 racks at bottom, for subsequent re-opening for maintenance or other.
