Ecodry IN+ CN+ - Manual of installation, use and maintenance
5.4 Dimensions
5.4.1 Vertical unit IN+, front supply
Ecodry IN+CN+_20190801 Page  di  Rossato Group Srl23 43
electrical supply
Condensation discharge
control
air inlet
Filter for air intake
condensation discharge
Air inlet
Control
Filter for air intake
Electrical supply
IN 1/2” gf
OUT 1/2” gf (hysothermic version
OUT 1/2” gf (hybrid version)
