Rotary M50 User Manual

5 CHAPTER 5 - TECHNICAL SPECIFICATION
5.1 SIZE AND MAIN FEATURES (Ref. Figure 5)
Capacity
5000 Kg
Maximum lifting height
1850 mm
Minimum height of lift
360 mm
Length of the lift
4600/5200 mm
Width of the lift
~ 2250* mm
Width of platforms
668 mm (N-LT) / 704 mm (AT-LTAT)
Free width between platforms
886* mm (N-LT) / 850* mm (AT-LTAT)
Lifting time
~ 60 s
Lowering time
~ 60 s
Noise level
70 dB(A)/1m
Total weight of the lift
Kg.1800(N)-1900(AT)
2400(LT)-2500(LTAT)
Working temperature
-10 °C  40 °C
Compressed air pressure
6 bar
5.2 ELECTRIC MOTOR
Type
90LA/4
Power
3 KW
Voltage
230 V / 400V
Frequency
50 Hz
N° Poles
4
Speed
1400 rpm
Motor enclosure type
B5
Insulation class
IP 54
Amperage
13.5 A a 230 V
8 A a 400 V
Motor connection must be carried out referring to the attached wiring diagrams (rif. Figura 6).
The motor direction of rotation is shown in the label placed on the motor.
5.3 PUMP
Type
gear
Flow rate
5 cm
3
/g
Continuous working pressure
210 bar
Frequent working pressure
230 bar
Peak pressure
245 bar
