Rotary M50 - 2 Movements Play Detector Hydraulic Unit; 8 Movements Play Detector Hydraulic Unit

Figure 14 – 2 MOVEMENTS PLAY DETECTOR HYDRAULIC UNIT
Figure 15 - 8 MOVEMENTS PLAY DETECTOR HYDRAULIC UNIT
The hydraulic unit of eight movements play-detector has a solenoid valve for the left/right
movement upper plate (1), a solenoid valve for the front/rear movement lower plate (2) and one
solenoid valve for release upper and lower plates
