Rotary M50 User Manual

5.4 HYDRAULIC UNIT
Hydraulic unit changes according to models:
“N” and “AT” models are equipped with aluminum block on which are installed :
 (1) not used
 (2) platforms leveling solenoid valve (EV2)
 (3) platform lowering solenoid valve (EV3)
 (4) platform commutation solenoid valve (EV4)
 (5) max pressure valve
 (6) check valve
 (7) platform lowering control valve
 (8) not used
 (9) hand pump
Figure 6 – HYDRAULIC BLOCK
MODELS “N” AND “AT”
