Effectivity: 912 i Series BRP-Powertrain page 1-11
OM Edition 1/Rev. 2 April 01/2014
d05694.fm
1.6) Standard version
Serial production - 4-stroke, 4 cylinder horizontally opposed, spark ignition en-
gine, single central camshaft push rods - OHV
- Liquid cooled cylinder heads
- Ram air cooled cylinders
- Dry sump forced lubrication
- Fully redundant electronic engine management (EMS) in-
cludes fuel injection, characteristic ignition, etc.
- Propeller drive via gearbox with integrated mechanical shock
absorber and overload clutch
- Oiltank
- Electric starter (12 V 0.8 kW)
- Fuel pump assy.
Optional - Preparation for hydraulic governor for constant speed propel-
ler: (configuration 3 only)
- Exhaust system
- Cooling air baffle
- Engine suspension frame
