Effectivity: 912 i Series BRP-Powertrain page 3-3
OM Edition 1/Rev. 0 January 01/2012
d05696.fm
Coolant level
Expansion tank
Fig. 1
The coolant specifications of the section
Chapter 2.2) Operating media are to be ob-
served!
Step Procedure
1 Verify coolant level in the expansion tank, replenish as re-
quired up to top. The max. coolant level must be flush with
the bottom of the filter neck. See Fig. 1
.
2 Verify coolant level in the overflow bottle, replenish as re-
quired.
The coolant level must be between max. and min. mark.
See Fig. 1
.
Protect the environment and never spill any coolant.
Part Function
1 Radiator cap
2 Expansion tank
