Rotax 912 i series Operator's Manual

Effectivity: 912 i Series BRP-Powertrain page 4-6
OM Edition 1/Rev. 0 January 01/2012
d05873.fm
4.14) Maximum permissible exhaust temperature exceeded
Exceeded ex-
haust temperature
- Check the exhaust temperature.
- Oil and coolant limits must not be exceeded.
- A maintenance inspection should be carried out.
4.15) EMS voltage supply below the minimum required level
Voltage supply be-
low level
- Limited flight operation is possible if the voltage (alternator A
or B) is OK here.
- Proceed according to section: „Failure of the EMS power sup-
ply“ if this shows no effect.
- A maintenance inspection should be carried out.
4.16) The sprag clutch decouples not from the starter
Spag clutch is per-
manently in en-
gagement position
- Move the throttle lever to the idle position.
-Set the EMS main switches to “OFF“.
- Switch both LANE select switches to “OFF“.
- A maintenance inspection should be carried out.

WARNUNG
NOTICE
Reduce engine power setting to the minimum
necessary and carry out precautionary land-
ing.

WARNUNG
NOTICE
Reduce engine power setting to the minimum
necessary and carry out precautionary land-
ing.

WARNUNG
NOTICE
Switch the engine “OFF“. Risk of fire and dan-
ger of the electric starter overheating.

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
