Rotax 912 i series Operator's Manual

Effectivity: 912 i Series BRP-Powertrain page 4-7
OM Edition 1/Rev. 0 January 01/2012
d05873.fm
4.17) Trouble shooting
Introduction All checks in accordance with the Maintenance Manual (current
issue/revision).
Table of content This chapter of the Operators Manual contains possible cause
and remedy in case of trouble shooting.

WARNU

WARNING
Non-compliance can result in serious injuries
or death!
Only qualified staff (authorized by the Avia-
tion Authorities) trained on this particular en-
gine, is allowed to carry out maintenance and
repair work.

WARNUNG
NOTICE
If the following hints regarding remedy do not
solve the problem, contact an authorized
workshop. The engine must not be operated
until the problem is rectified.
Subject Page
Starting problems Page 4-8
Engine run Page 4-8
Oil pressure Page 4-8
Oil level Page 4-9
Cold engine start Page 4-9

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
