Rotax 912 i series Operator's Manual

Effectivity: 912 i Series BRP-Powertrain page 4-9
OM Edition 1/Rev. 2 April 01/2014
d05873.fm
Oil level Oil level is increasing
Cold engine start Engine hard to start at low temperature
Possible cause Remedy
Oil too cold during engine op-
eration.
Cover oil cooler surface, maintain the
oil temperature prescribed.
Contamination with diesel fuel. Check fuel.
Possible cause Remedy
Starting speed too low. Preheat engine.
Low charge battery. Fit fully charged battery.
High oil pressure. At cold start a pressure reading of up to
around 7 bar (102 psi) does not indi-
cate a malfunction.
Oil pressure too low after cold
start.
Too much resistance in the oil suction
system at low temperatures due to cold
oil. Stop engine and preheat oil.
After a cold start the oil tank must be
observed and the pressure should be
above 1.5 bar (22 psi). Otherwise, the
speed must be lowered again, because
not enough cold oil can be sucked.
If oil pressure is reading lower than
1 bar (15 psi) oils with lower viscosity
are to be used.
See SI-912 i-001, current issue.
NOTE: Oil pressure must be measured at idle at an oil tem-
perature of minimum 50 °C (120 °F).
Be sure the oil pressure does not go below mini-
mum at idle.

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
