Rotax 912 i series Operator's Manual

Effectivity: 912 i Series BRP-Powertrain page 5-1
OM Edition 1/Rev. 0 January 01/2012
d05697.fm
5) Performance data
Introduction The performance tables and performance graphs on the next few
pages are intended to show you what kind of performance to ex-
pect from your engine in terms of power output. The indicated
power can be achieved by following the procedures laid out in the
Operators Manual and ensuring that the engine is well-main-
tained.
Table of content This chapter of the Operators Manual contains performance table
and performance graphs.
Subject Page
Performance data for standard conditions (ISA) Page 5-2
Fuel consumption 912 iSc/iS Page 5-3
Performance data for variable pitch propeller Page 5-4
Performance graph for non-standard conditions Page 5-5

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
