Rotax OM-912 Installation Manual

d04924.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
75-00-00
page 22
August 01/2012
Graphic
Hose nipple
Fig. 10 09132,05033,09126
Part Function
1Nut M6
2Cap
3 Hose nipple
4 Gear-type hose clamp
5Hose
6 Bypass opening (slot)
7 Cowling
11,5mm
(0.453 in)
Ø
6
(0.236 in)
mm
Ø
3
(0.118 in)
mm
Ø
6
(0.236 in)
mm
1 2 3
4
5
6 mm (0.236 in.)
LOCTITE 603
2
1
3
6
7
5
