d04922.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
72-00-00
page 5
August 01/2012
Top view
Fig. 4 00504
Part Function
15 Mechanical fuel pump
16 Exhaust socket
17 Intake manifold
18 Electronic module
19 Electric starter
20 Ignition housing
21 Engine number
22 Expansion tank
23 Connection for manifold pressure
24 External alternator
A
A
-x
+x
-y
+y
P
-x1
+y1
-y1
+x1
17
21
16
17
24
15
20
18
22
23
19
Cyl. 1
Cyl. 3
Cyl. 2
Cyl. 4
