Values
Exhaust gas temperature (EGT):
(both ignition circuits active)
- Nominal exhaust gas temperature: 800 °C (1470 °F)
max. 850 °C (1560 °F)
- At take-off: max. 880 °C (1616 °F)
4.1) Data for optional components of exhaust system
Weight See also chap. 72-00-00.
Graphic Exhaust elbow
Material/thickness: X 15 CrNiSi20-12 (DIN 1.4828) (stainless steel) a =
1.5 mm (0.06 in).
Fig. 5
09164
80 (3.15 in.)
28 (1.11 in.)
a
