1.4) Protective covering
General note
All openings are protected against ingress of contamination and damp-
ness. It is recommended to leave the protective plugs in place until instal-
lation of the specific feed line.
NOTE: The transport equipment and plugs must be reattached if
the engine will be sent to the manufacturer or distributor.
Protective cover-
ing
List of protective covering:
Protective coverings are only for use during transport
and engine installation. They must be removed before
the engine is operated.
Installation place Number
Exhaust socket 1x cone plug
Connection for manifold pressure 1x cap
Airbox 2x cap
Fuel pump inlet 1x cap
Connection for fuel return 1x plug
Connection for fuel pressure 1x plug
Oil supply and oil discharge 1x each cap
Supply and discharge of coolant 1x each cone plug
Propshaft on configuration 3 1x disk plug
Carburetor (if not equipped with an airbox) 2x disk plug
