INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
79-00-00
page 29
August 01/2012
4) Data for optional components of lubrication system
4.1) Oil cooler
General note See Fig. 14.
Weight See also chap. 72-00-00 sectiont: weight.
4.1.1) Variants of connectors
General note
UNF screw socket
Nipple 13.2/9.2
Metric screw socket
Counter hold screw sockets when securing the oil
lines.
UNF screw socket
Thread 3/4-16 UNF (AN-8)
Tightening torque 22 Nm (16.23 ft.lb) and LOCTITE 648
Tightening torque of oil feed line
and outlet
25 Nm (18.5 ft.lb)
Nipple
Outer dia. 13.2 mm (0.52 in)
Slip-on length max. 21 mm (0.83 in)
Tightening torque 22 Nm (16.23 ft.lb) and LOCTITE 243
Counter hold screw sockets when securing the oil
lines.
Metric screw socket
Thread M18x1,5
Tightening torque 22 Nm (16.23 ft.lb) and LOCTITE
648
Tightening torque of oil feed line
and outlet, bent socket or hose
nipple
25 Nm (18.5 ft.lb)
