Rotax OM-912 Installation Manual

d04925.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
76-00-00
page 10
August 01/2012
2.1) Air temperature in the airbox (optional)
General note See Fig. 6.
To take air temperature readings in the airbox a connection is provided.
This connection is closed on the standard engine by a plug screw.
Plug screw Connection:
Graphic Airbox
Fig. 6
08647
Thread M6
Thread length approx. 9 mm (3/8“)
Part Function
1 Plug screw
1
