d04927.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
79-00-00
page 17
August 01/2012
Graphic
OIl tank
Fig. 10 08799
Part Function
1 Oil tank
2 Bayonet cap
3 M12x12 hex. screw
4 C12x18 gasket ring
5 Oil dipstick
6 M10x1 plug screw
7 A10x14 gasket ring
8 Profile clamp 163
9 Oil tank cover assy. (UNF 3/4-16)
10 Oil tank cover assy. (metric M18x1.5)
WARNUNG
NOTICE
If the lines are connected incorrectly, the engine will
not be lubricated and the engine will be damaged very
quickly!
