d04920.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
24-00-00
page 12
August 01/2012
Graphic
Assembly of the flat pin terminal
Fig. 6 08323
Part Function
1 Cable grommet
2 Flat pin terminal
3 Wiring (airframe)
4 Crimping pliers
5 Position in the connector housing
1
3
1
4
2
5
2
