INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
24-00-00
page 20
August 01/2012
Legend to wiring diagram
Fig. 11 08639
Part Function Part Function
1 2 Electronic modules (A
and B)
17 Starter switch
2, 3 Plug connection for igni-
tion switch
18 Control lamp
4 Integrated generator 19 Battery relay
5, 6 External regulator - recti-
fier with plug connec-
tions
20 Battery
7 Electric starter 21 Bus Bar
8, 9 Starter relay with plug
connection
22 Capacitor
10, 11,
12
External alternator with
connection
23 Plug connection for
trigger coil assy.
13 Electric rev counter 24 Trigger coil assy.
(tachometer)
14 2 capacitor
22000 µF
25 Electrical fuel pump
15 2 ignition switches 26 Starting equipment
at the electronic
modules
16 Masterswitch
