d04921.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 Series
Edition 2/Rev. 0
61-00-00
page 8
August 01/2012
Connections
Gear ratio NOTE: Gear ratio from crankshaft to hydraulic governor is 1.842,
i.e. the propeller governor runs at 0.54 times engine speed.
Pay attention to manufacturers specifications!
Mounting pad AND20010
Thread M8
Thread length Max. 14 mm (0.55 in.)
Governor drive Internal spline 20/40 SMS 1834 NA
14x1.27x30x12
Power consumption Max. 600 W
Operating pressure Max. 30 bar (435 psi)
