PM-GP-002 Page: 1/1
Component: Single-Acting actuator
Double-Acting actuator
Task: Functional test
Equipment, Tools, Materials:
Chronometer
Project documentation (required stroke times)
Warnings:
Preliminary Operations:
Description:
NOTE: Actuator must be connected to the pneumatic supply to perform the following test.
1. Operate the actuator
2. Perform the stroke several times by local and remote (if applicable) control
Actuator could exhaust medium supply in the atmosphere during normal operation.
Wear PPD including breathing device in function of type of medium supply used.
3. Verify actuator is correctly working
4. Note the stroke time(s)
5. Verify stroke time(s) are as required
In case of stroke times out of required range refer to Troubleshooting ID 4, 5 (see page 30) to restore.
