Only MultiHost 802.1X is the type of authentication supported in the switch.
In this mode, for the devices connected to this port, once a supplicant is authorized,
the devices connected to this port can access the network resource through this
port.
802.1X Port-based Network Access Control function supported by the switch
is little bit complex, for it just support basic Multihost mode, which can distinguish
the device’s MAC address and its VID. The following table is the summary of the
combination of the authentication status and the port status versus the status of port
mode, set in 802.1X Port mode, port control state, set in 802.1X port setting. Here
Entry Authorized means MAC entry is authorized.
Port Mode Port Control Authentication Port Status
Disable Don’t Care Don’t Care Port Uncontrolled
Multihost Auto Successful Port Authorized
Multihost Auto Failure Port Unauthorized
Multihost ForceUnauthorized Don’t Care Port Unauthorized
Multihost ForceAuthorized Don’t Care Port Authorized
Table 3-3
3-10-1.Server
Function name:
802.1X Server Configuration
Function description:
This function is used to configure the global parameters for RADIUS
authentication in 802.1X port security application.
Parameter description:
Authentication Server
Server IP Server:
Server IP address for authentication.
Default: 192.168.1.1
UDP Port:
Default port number is 1812.
Secret Key:
The secret key between authentication server and authenticator. It is a
string with the length 1 – 31 characters. The character string may
contain upper case, lower case and 0-9. It is character sense. It is not
allowed for putting a blank between any two characters.
Default: Radius
Accounting Server
Server IP Server:
