3-6-2. Qos Control List
Function name:
Qos Control List Configuration
Function description:
The
switch support four QoS queues per port with strict or weighted fair
queuing scheduling. There are 24 QoS Control Lists (QCL) for advance
programmable QoS classification, based on IEEE 802.1p, Ether Type, VID,
IPv4/IPv6 DSCP and UDP/TCP ports and ranges.
Fig. 3-35
Delete this entry
Insert an entry
Edit this entry
Move up this entry
Move down this entry
To Next Page
