Ruby Tech GS-2224L User Manual

7
1-4. Full View of GS-2224L
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 24 TP Gigabit Ethernet ports and 2 SFP fiber ports for optional
removable modules on the front panel of the switch. LED display area, locating on
the left side of the panel, contains a Power LED, which indicates the power status
and 24 ports working status of the switch. One RS-232 DB-9 interface is offered for
configuration or management.
Fig. 1-1 Full View of GS-2224L
Fig. 1-2 Front View of GS-2224L
Power Indication LED
Gi
g
abit Ethernet Port
RESET Button:
RESET button is used
to reset the
mana
g
ement s
y
stem.
SFP Fiber Port
Fiber Port Status Indication LEDs
RS-232 DB-9 Connector
