Ruida Technology RDC6445S - Interface of Main Power Source CN0; Panel Signal-Cable Interface HMI; Udisk Interface; PC-USB Interface

RDC6445G/S Control System manual
SHENZHEN RUIDA TECHNOLOGY
14
4.1 Interface of Main Power Source CN0
4.2 Panel Signal-Cable Interface HMI
The panel signal-cable is a pin-to-pin cable, which is included in the factory
shipper bill.
4.3 Udisk Interface
Udisk is a USB-AM interface. The controller may visit the u-disk by this interface.
4.4 PC-USB Interface
PC-USB is a USB-BM interface. The controller may communicate with PC by this
port.
4.5 Ethernet Interface
Using this interface, the mainboard can communicate with PC by 10/100MHZ
Ethernet.
Pin to Pin Ethernet parallel line is recommended.
4.6 General Output Port CN1
Definition of general output port
Pin
Symbols
Definitions
1
GND
24V power ground (input)
2
+24V
24V power positive (input)
This control system employs single 24 power supply. For a certain
margin, it is suggested to select 24V/2A power. Besides, this system is
compatible with 36V power, that is to say, the 36V power of Motion
driver can directly be connected to this main power port of this system,
but generally it is not suggested to do so.
Caution
Caution
