KT332N Cutting &engraving control system user manual V1.1
5.1 Overview
This control system has two independently adjustable laser power control interfaces, which can
control glass tube laser power and RF CO2 laser.
When connecting different laser power types, please set the laser type correctly in the
factory parameters, otherwise it cause to the switching light may be incorrect.
5.2 Glass tube laser power wiring diagram
5.3 RF CO2 laser wiring diagram
