• Any blue text can be clicked on to jump directly to the page of that
topic. (This document is also printer-friendly, so you can have it in
front of you while servicing the mower.) If you print this document,
we recommend printing it in landscape mode and in color
• A Block Diagram shows the general flow to visualize how the mower is
connected and a chart shows general symptoms/solutions for repairs.
• Electronics tips
, Terminology, and Using a Digital Multi-Meter (DMM)
are included for the technician familiar only with gas machines.
Using this Document
4
