Block Diagram: Control Flow
16
80V
Batteries
Main Fuse
Charge Port
80V to 12V
DCDC
Converter
Relay
Brake
Switch
Beeper
Seat
switch
Fuse
Primary
Blade
Control
Secondary
Blade
Control
Motor
Motor
Head
Lights
Transducers
IMPORTANT
Primary and secondary have a
communication link. If one blade
motor or controller fails, BOTH
will shut down.
USB
80V
Secondary
Drive
Controller
P
PTO
Key
Switch
12V
5V out
Motor
Hall Sensors
Primary
Drive
Controller
Motor
Hall Sensors
Neutral
Switch
Enable
40V
Batteries
Boosters
Mixing
Board
TIC
Junction Box
LCD
Bagger Boost
