Error Codes
Confidential and Proprietary - Property of Techtronic Power Equipment - DO NOT COPY or DISCLOSE
INDICATOR CODE MEANING BIT MEANING
A0 Drive Controller data0
7 Motor Hall Sensor fault
6 Over-temperature
5 Communication failure
4 Under voltage
3 Seat Switch failure
2 Motor stall
1 Overcurrent
0 Unit operating; key on, accelerator not in “zero” location – NOT AN ERROR
EXAMPLE ERROR CODE: A0 0000000
A0
This INDICATOR CODE
shows the area where
the error is present.
0
Bit7
0
Bit6
0
Bit5
0
Bit4
0
Bit3
0
Bit2
0
Bit1
0
Bit0
The BIT CODE indicates the error(s). A 0 in the space
indicates No Error. A 1 in the space indicates an Error.
INDICATOR CODE KEY
CODE MEANING
A0 Drive Controller data0
A1 Drive Controller data1
B0 Deck Controller data0
B1 Deck Controller data1
B2 Deck Controller data2
B3 Deck Controller data3
B4 Deck Controller data4
B5 Deck Controller data5
B6 Deck Controller data6
C0 Permanent Battery Failure
