Level M3 : Error Log
3.1 Errors List
The following are shown at this level:
-) The last 20 errors involving the CA
-) The date the error occurred.
The error map is shown below:
3.2 Clear all?
pressing YES will delete all errors at level 3.1.
Code Brief description Description
COFFEE GRINDER ERRORS
01
Coffee grinder blocked. The coffee grinder won’t turn: there may be something obstructing
the grinders or beverage signal has not been read correctly by the Hall
probe in the coffee grinder.
BREW GROUP ERRORS
03
TORQUE_FAULT_FWD Maximum force exceeded in forward movement to dispense position
(second attempt).
TIMEOUT_FWD Maximum time exceeded to reach dispense position.
TIMEOUT_FWD_DOWN Maximum time exceeded to clear home position microswitch.
HOME_WHILE_WORKING Home position microswitch activated while moving to work position.
04
TORQUE_FAULT_RWD Maximum force exceeded returning to home position.
TIMEOUT_RWD Maximum time exceeded returning to rest position.
WORK_WHILE_HOMING Work position microswitch activated while moving to home position.
16
HOME_AND_WORK_PRESSED Both the work and home microswitches are activated at the same time.
WATER CIRCUIT ERRORS
05
Water circuit blocked. This can happen for a variety of reasons ...(trips when water not flow-
ing in turbine).
TEMPERATURE CONTROL ERRORS
10
SENSOR1_SHORT Coffee heater sensor shorted.
11
SENSOR1_OPEN Coffee heater sensor in open circuit.
14
TEMPERATURE_BO_TOO_HIGH Coffee heater temperature too high.
15
TEMPERATURE_BO_OUT_CONTROL Coffee heater temperature out of control (not responding to stimuli:
e.g. heater on but temperature not rising).
GENERAL ERRORS
19
No zero crossing. No zero crossing on card, could be caused by power card.
14/17
TALEA Section 05
REV00 - August 06
