Saeco Talea Touch - Talea Ring Machine Components

Ideas with Passion
Pre-ground coffee bin
Brew grou
p
Coffee grounds drawer
Power cable cup connector
Coffee granule containe
r
Main switch
Service door
Coffee granule container
cover
Drip tray
Control panel
SB
S
Brew group
Drip tray + grid and float
Water tank
Hot water/steam valve knob
“Milk Island” connectio
n
Hot water dispense pipe (spout
)
Cup warming plat
e
(Only for Ring Plus)
Button to raise/lower drip tray
(Motorized on Ring Plus only)
Talea Ring
3/4
TALEA Section 02
REV00 - August 06
