6.7 Milk Island
Electrical connec-
tion to appliance.
Water pipe connected to
appliance for steam inlet.
Button to
attach/release
Milk Island
from appliance.
Steam
outfeed
Carafe
present
LED
Anchor pin
between Milk Island
and appliance.
Unscrew bolts
indicated to
dissassemble.
2
1
3
4
5
6
7
8
9
Cappucinatore cover.
Cappucinatore valve cover.
Vernay valve.
Cappucinatore valve
cover insert.
Cappucinatore body.
Carafe handle.
Carafe milk suction pipe.
Carafe steamout pipe.
Top part carafe.
2
1
3
4
5
6
7
8
9
