2.1 Product technical data
Power supply and output: 230 V~, 50/60 Hz, 1300 W.
Temperature control: 1 (NTC) variable resistor sensor – transmits the value
to the electronic board.
Safety system: 2 x 175°C manual reset thermostats.
Coffee heat exchanger output:
Stainless steel
1300 W – to dispense coffee, hot water and steam.
Motorized tank only on
Talea Touch and Ring Plus.
24V stepper motor.
Water level
and drip
tray sensor:
Capacitive sensor
Gearmotor: 33VC with 2 directions of rotation.
Cup warmer plate:
Solo Talea Touch and Ring Plus
Activated via MENU display.
PTC Type.
Pump: Ulka reciprocating piston type with thermal cutout at
100°C,
48 W, 230V, 50 Hz, Type EX5 approx. 13-15 bars.
Pressure relief valve: Opening at approx. 18-20 bars.
Water filter: In tank.
Coffee grinder: DC motor with ceramic plate
grinders.
Solenoid pilot: 15 VA.
Coffee dose control: Hall sensor – Pulse control. Dose adjustment can
be set from approx. 7 to 10.5 g.
Amps: During heating phase- approx. 5.6 A.
Dimensions: l x h x d in mm: 300/375/410
Weight: 10 kg (average).
Water tank capacity: 1.7 l.
Coffee container capacity: 250g coffee granules.
Coffee grounds drawer capacity:
14
Heatex changer capacity: Approx. 10 cc.
Water circuit filling time: Approx. 15 sec on first filling cycle.
Heating time: Approx. 45 sec.
Dispensed drink temperature: Approx. 73°C - 83°C
Grinding time: Approx. 8-10 sec.
1/4
TALEA Section 02
REV00 - August 06
