Chapter 12: Constant List
Firmware – S2011 and S3012
Revision: 1 (9/98) 88 © Saftronics, Inc.
Table 27 Constant List (Continued)
Constant Function Name Description
Factory
Setting
n082
Output phase loss detection level
(SPO)
Unit : 1%
Setting range : 0 to 100%
0%
n083
Output phase loss detection delay time
(SPO)
Unit : 0.1 seconds
Setting range : 0.0 to 2.0 seconds
0.2 seconds
n084 PID selection (same as PID LED)
0 : PID disabled
1 : PID enabled (Deviation is D-controlled)
2 : PID with feed forward (Feedback value is D-controlled)
3 : PID with feed forward (Feedback is reversed characteristics)
0
n085 Feedback calibration gain (PID)
Unit : 0.01
Setting range : 0.00 to 10.00
1.00
n086 Proportional gain (PID)
Unit: : 0.1
Setting range : 0.0 to 10.0
1.0
n087 Integral time (PID)
Unit : 0.1 seconds
Setting range : 0.0 to 100.0 seconds
10.0
seconds
n088 Derivative time (PID)
Unit : 0.1 seconds
Setting range : 0.0 to 100.0 seconds
0.00
seconds
n089 Offset (PID)
Unit : 1%
Setting range : − 109 to 109%
0%
n090 Limit of integral value (PID)
Unit : 1%
Setting range : 0 to 109%
100%
n091 Output lag filter time (PID)
Unit : 0.1 seconds
Setting range : 0.0 to 2.5 seconds
0.0 seconds
n092 Feedback loss detection (PID)
0 : Detection is disabled
1 : Detection is enabled
0
n093 Feedback loss detection level(PID)
Unit : 1%
Setting range : 0 to 100%
0%
n094
Feedback loss detection delay time
(PID)
Unit : 0.1 seconds
Setting range : 0.0 to 25.5 seconds
1.0 seconds
n095
Energy Saving selection
(same as kWsav LED
0 : Energy Saving is disabled
1 : Energy Saving is enabled
0
n096 Energy Saving gain K2
Unit : 0.01 (0.1 for 100.0 or above)
Setting range : 0.00 to 655.0
kVA
dependent
n097
Energy Saving voltage lower limit at
60Hz
Unit : 1%
Setting range : 0 to 120%
50%
n098
Energy Saving voltage lower limit at
6Hz
Unit : 1%
Setting range : 0 to 25%
12%
n099 Time of average k W (Energy Saving)
Unit : 1 = 25ms
Setting range : 1 to 200
1
n100 Voltage limit of tuning (Energy Saving)
Unit : 1%
Setting range : 0 to 100%
0%
n101
Step voltage of tuning at 100% output
voltage (Energy Saving)
Unit : 0.1%
Setting range : 0.1 to 10.0%
0.5%
n102
Step voltage of tuning at 5% output
voltage (Energy Saving)
Unit : 0.1%
Setting range : 0.1 to 10.0%
0.2%
n103 MEMOBUS time over detection
0 : Time over detection is disabled
1 : Time over detection is enabled
1
n104
MEMOBUS stop method at
communication error (CE)
(Setting) (Stop Method)
0 : Ramp to stop − Decel 1 (fault)
1 : Coast to stop (fault)
2 : Ramp to stop − Decel 2 (fault)
3 : Continue operation (alarm)
1
n105 MEMOBUS frequency reference unit
(Setting) (Frequency Unit)
0 : 0.1Hz / 1
1 : 0.01Hz / 1
2 : 100% / 30000
3 : 0.1% / 1
0
n106 MEMOBUS slave address
Unit : 1
Setting range : 0 to 31
0
n107 MEMOBUS BPS selection
(Setting) (BPS Rate)
0 : 2400 BPS
1 : 4800 BPS
2 : 9600 BPS
2
n108 MEMOBUS parity selection
(Setting) (BPS Rate)
0 : No parity
1 : Even parity
2 : Odd parity
1
