6-
dvanced parameters
Page 6-24 F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
6.4.2.2 Ethernet over ATM – PPP over Ethernet (PPPoE)
• Select the WAN service type PPP over Ethernet (PPPoE).
Field
Action
Default value
Enter Service
Description
Displays the name of the service being configured. This
name, which is allocated automatically, is made up as
follows: Protocol_VPI_ Index _ VCI
For example: pppoe_eth0.
Note: You may enter another service name.
pppoe_eth0
Enter 802.1P Priority
a
Enter a value for the 802.1P Priority. This value is
between 0 and 7.
-1
Enter 802.1Q VLAN
ID
a.
Enter a value for the 802.1QVLAN ID. This value is
between 0 and 4094.
-1
Network Protocal
Selection
Select the type of network from the drop-down list:
• IPv4 Only
• IPv4&IPv6 (Dual Stack)
IPv4 Only
a. These values only appear if the WAN service is configured over a DSL ATM interface using VLAN MUX
Mode.
