Sakura Tissue-Tek TEC 6 User Manual

1. Introduction
19
1.4 Overview of the Instrument
1.4.1 Instrument Conguration
The instrument comprises:
A storage area where the parafn-inltrated tissues (specimens), base molds
and molten parafn used for embedding are kept at appropriate temperatures;
A hot plate that performs a key part of embedding:
A cold spot used for positioning and orienting the tissue;
A dispenser that dispenses parafn for embedding;
A cooling plate that cools/solidies the embedded parafn block; and
Electronic controls, control panel display and other parts for temperature-
controlling, monitoring or otherwise manipulating the aforementioned
components.
Embedding Module
CAUTION
• The instrument is designed for use with the Cryo Module
connected with the control cable. Do not connect any other
instruments.
CAUTION
