Salus SQ610 Quantum User Manual

52
7.2 Pairing with underoor heating wiring centre (KL08RF/Control Box)
1
4
7
5
6
Select system type: UNDERFLOOR,
press
button to conrm.
Using
and buttons
select the Control Box number.
Press
button to conrm.
Use
or buttons to select
the zone number and press
button to conrm.
8
You can pair your thermostat with
more than one zone. Select additional
zones or nish the pairing process by
button.
REPLACE ZONE:
If user during pairing process will choose already occupied zone then thermostat will display „ZONE OCCUPIED” message. Occupied zone can be replaced
by other thermostat. It will remove current thermostat assigned to that zone. Please look at the steps below:
1
2
Now thermostat is looking for the
signal from the coordinator...
When thermostat is succesfully
paired main screen will be
displayed.
2
PLEASE NOTE!
For easier installation, please make sure you have already added underoor heating wiring centre (KL08RF/Control Box) to your ZigBee network (please
refer to the underoor heating wiring centre manual instruction).
3
Open the ZigBee network
OR
5 sec.
5 sec.
9
Close the ZigBee network
OR
3
3
5 sec.
5 sec.
Select “YES” by „ ” or „ ”
buttons. Conrm by button.
