9
4. Before you start (rst power up)
1. Menu/Settings description + Clock
2. AM/PM
3. Temperature unit
4. Heating indicator (icon is animating when there is heating demand)
5. Cooling indicator (icon is animating when there is cooling demand)
6. RF Connection indicator
7. Internet conection indicator
8. Occupancy sensor (hotel card)
9. Key lock function
10. Standby mode icon
11. Current Temperature / Setpoint Temperature
12. Holiday mode
13. Temporary override mode
14. Settings icon
15. External / Floor temp sensor indicator
16. Schedule program number
17. Schedule mode icon
18. Day indicator/ SET information
19. Humidity Display
+
Button
Function
In the MAIN SCREEN - press and hold these buttons together for 3 seconds to LOCK / UNLOCK the thermostat keys).
„Down” Button (Decrease parameter value/moving on the menu in ‘DOWN’ direction)
“Up” Button (Increase parameter value/moving on the menu in ‘UP’ direction)
1) “OK / Tick” Button (Conrm parameter value / Go to the next menu / Save settings)
2) In the MAIN SCREEN: Press and hold for 3 seconds to enter Standby mode
3) In the SETTINGS SCREEN: Press and hold for 3 sec to go back to the MAIN SCREEN & SAVE all the changes.
1) Menu button / Return button.
2) In the MAIN SCREEN: Press and hold for 3 sec to change the thermostat operating mode
(Schedule mode / Permanent mode).
3) In the SETTINGS SCREEN: Press and hold for 3 sec to go back without saving the changes.
4) In the PAIRING SCREEN (in SYSTEM TYPE Menu): Press and hold for 3 sec to see other
pairing options.
Button Description
4.2 Button Description
4.1 LCD Icon Description
2
8
9
10111214
19
18
17
16
15
1
3
4
5
6
7
13
