Salus SQ610 Quantum User Manual

54
7.4 Pairing with Receiver RX10RF
2
4
Press button for 3 seconds to expand
“SYSTEM TYPE” menu.
5
Use or buttons to:
- choose pairing with the RX10RF receiver in the
„RX1” conguration, if the receiver is set as RX1
(receiver responds to the heating signal from any
thermostat),
- choose pairing with the RX10RF receiver in the
„RX2” conguration, if the receiver is set as RX2
(receiver responds to the heating signal from only
one thermostat).
Conrm by button
6
After all you will see the main
thermostat’s display.
1
PLEASE NOTE!
For easier installation, please make sure you have already added RX10RF receiver to your ZigBee network (please refer to the RX10RF receiver manual
instruction).
Now thermostat is looking for the
signal from the coordinator...
3
Open the ZigBee network
OR
5 sec.
5 sec.
7
Close the ZigBee network
OR
5 sec.
5 sec.
3
3
Select “YES” by „ ” or „ ”
buttons. Conrm by button.
