- 47 -
E.2 Drawer Connector
Pin No. Signal name Direction
1 Frame Ground -
2 Drawer kick- out drive signal 1 Output
3 Drawer open/close signal Input
4 +24V -
5 Drawer kick- out drive signal 2 Output
6 Signal Ground -
