2.Productspecicationanddescription

2.2.SystemOverview

Thischapterdescribesthefunctionsandoperatingprincipalofthemaincomponent.

2.2.1.FrontView

NOTE

•Thisillustrationmaydifferfromyourmachinedependingonyourmodel.Therearevarioustypesofmachine.

•Somefeaturesandoptionalgoodsmaynotbeavailabledependingonmodelorcountry.

M2070/M2070W

1Scannerlid

2Controlpanel

3Handle

4Tray

5Trayhandle

6Outputsupport

7Outputtray

8Scannerglass

9Scanunit

10Innercover

11Tonercartridge
