2.Productspecicationanddescription

2.2.5.1.Mainboard

A1500chipisadoptedasthemainprocessor.Itsprocessspeedis600MHz.Itisintegratedenginecontroller,video

controller,scancontroller.

DDR2128MBisadoptedforhighspeeddataprocessing.

USBistheembeddedtypeandwirednetworksupports100Mfullduplex.

[Mainboardimage]

•Connection

1LSUconnector

2CRUMconnector

3EngineMotorconnector

4SMPS/HVPSinterfaceconnector

5Wirelessmoduleinterfaceconnector

6Faxboardinterfaceconnector

7Sensorconnector

8Pickupconnector

9Wirednetworkconnector

10USBdeviceconnector

11ADFModuleinterfaceconnector

12OPEconnector

13CISinterfaceconnector

14Fuserthermistorinterfaceconnector

•Information

-Partcode

▪M2070:JC92-02688B

▪M2070W:JC92-02688A

▪M2070F:JC92-02689B

▪M2070FW:JC92-02689A

-Partname:PBA-MAIN
